S16: Names placement



3. Graphic variables of text - 3d) line- and letterspacing




Guiding rules:

  • Spacing may be appropriate for area features
  • Optional for visually bounded areas (islands, countries) - see Sulawesi


    The text "Sulawesi" should be spaced out from the gridlines (S u l a w e s i )

  • Mandatory for larger objects without visible boundaries - see Aceh


    Text should be spaced out from the gridlines
  • In combination with plastic name placement - see Aceh
  • If not plastic, fixed kerning is preferable

Preconditions for letter spacing:

  • the named object should be an area feature
  • in case of non-plastic name placement, the name should fit inside the boundaries of the named object
